| Item No. （Non-Rotatable） | Item No. （Rotatable） | Tube Diameter & Working Length | Working Channel Diameter | Scope Of Use |
| AF-D1810DC-1(A) | AF-D1810DC-1(B) | Ø1.8x1000mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1812DC-1(A) | AF-D1812DC-1(B) | Ø1.8x1200mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1815DC-1(A) | AF-D1815DC-1(B) | Ø1.8x1500mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1816DC-1(A) | AF-D1816DC-1(B) | Ø1.8x1600mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1825DC-1(A) | AF-D1825DC-1(B) | Ø1.8x2500mm | ≥Ø2.0mm | Enteroscopy |
| AF-D2416DC-1(A) | AF-D2416DC-1(B) | Ø2.4x1600mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2418DC-1(A) | AF-D2418DC-1(B) | Ø2.4x1800mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2421DC-1(A) | AF-D2421DC-1(B) | Ø2.4x2100mm | ≥Ø2.8mm | Colonoscopy |
| AF-D2423DC-1(A) | AF-D2423DC-1(B) | Ø2.4x2300mm | ≥Ø2.8mm | Colonoscopy |
Optional rotatable and non-rotatable. Cut polyp with high-frequency current. Special alloy strands easy control of cutting and solidification.
| Item No. （Non-Rotatable） | Item No. （Rotatable） | Tube Diameter & Working Length | Working Channel Diameter | Scope Of Use |
| AF-D1810DM | AF-D1810DMR | Ø1.8x1000mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1812DM | AF-D1812DMR | Ø1.8x1200mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1815DM | AF-D1815DMR | Ø1.8x1500mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1816DM | AF-D1816DMR | Ø1.8x1600mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1825DM | AF-D1825DMR | Ø1.8x2500mm | ≥Ø2.0mm | Enteroscopy |
| AF-D2416DM | AF-D2416DMR | Ø2.4x1600mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2418DM | AF-D2418DMR | Ø2.4x1800mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2421DM | AF-D2421DMR | Ø2.4x2100mm | ≥Ø2.8mm | Colonoscopy |
| AF-D2423DM | AF-D2423DMR | Ø2.4x2300mm | ≥Ø2.8mm | Colonoscopy |
Optional rotatable and non-rotatable. Cut polyp with high-frequency current. Special alloy strands easy control of cutting and solidification.
| Item No. （Non-Rotatable） | Item No. （Rotatable） | Tube Diameter & Working Length | Working Channel Diameter | Scope Of Use |
| AF-D1810DT | AF-D1810DTR | Ø1.8x1000mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1812DT | AF-D1812DTR | Ø1.8x1200mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1815DT | AF-D1815DTR | Ø1.8x1500mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1816DT | AF-D1816DTR | Ø1.8x1600mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1825DT | AF-D1825DTR | Ø1.8x2500mm | ≥Ø2.0mm | Enteroscopy |
| AF-D2416DT | AF-D2416DTR | Ø2.4x1600mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2418DT | AF-D2418DTR | Ø2.4x1800mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2421DT | AF-D2421DTR | Ø2.4x2100mm | ≥Ø2.8mm | Colonoscopy |
| AF-D2423DT | AF-D2423DTR | Ø2.4x2300mm | ≥Ø2.8mm | Colonoscopy |
Optional rotatable and non-rotatable. Cut polyp with high-frequency current. Special alloy strands easy control of cutting and solidification.
| Item No. （Non-Rotatable） | Item No. （Rotatable） | Tube Diameter & Working Length | Working Channel Diameter | Scope Of Use |
| AF-D1810DL | AF-D1810DLR | Ø1.8x1000mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1812DL | AF-D1812DLR | Ø1.8x1200mm | ≥Ø2.0mm | Bronchoscopy |
| AF-D1815DL | AF-D1815DLR | Ø1.8x1500mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1816DL | AF-D1816DLR | Ø1.8x1600mm | ≥Ø2.0mm | Gastroscopy |
| AF-D1825DL | AF-D1825DLR | Ø1.8x2500mm | ≥Ø2.0mm | Enteroscopy |
| AF-D2416DL | AF-D2416DLR | Ø2.4x1600mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2418DL | AF-D2418DLR | Ø2.4x1800mm | ≥Ø2.8mm | Gastroscopy |
| AF-D2421DL | AF-D2421DLR | Ø2.4x2100mm | ≥Ø2.8mm | Colonoscopy |
| AF-D2423DL | AF-D2423DLR | Ø2.4x2300mm | ≥Ø2.8mm | Colonoscopy |
Optional rotatable and non-rotatable. Cut polyp with high-frequency current. Special alloy strands easy control of cutting and solidification.
